Features
Features
- Compact design
- Metallic enclosure type 1
- Available in three box sizes M04, M06, and M08
- IEC contactors inside
- Trip class 10 bimetallic overload relays
- Phase loss sensitivity protection
- Automatic and manual RESET options
- Standard START/STOP + RESET buttons or RESET button only
- Easy to connect and operate
Specifications
Specifications
| Start Type | Direct Three-phase |
|---|---|
| Maximum Power Rating | Not applicable |
| Rated operational voltage | Ue<=600V |
| Control voltage | 180-208V50HZ/208-240V60HZ |
| Control devices | E-Reset |
| Degree of protection | TYPE1 |
| Starters Complements | Does Not Contain |
| Rated current (AC-3) | 50A (CWB50) |
| Overload relay | 32-50 A (RW67) |
| Measuring tool and accessories | Not Applicable |
| Button type | Unspecified |
| Button color | Not Specified |
| Connection Type | Not Applicable |
