Features
SVL1024100 SolaHD Power Supply (240W, 24V, DIN PS 85-264VAC)
- cULus, cRUus, CE
- Universal input, single-phase and three-phase models
- Short circuit, over voltage, overload and over temperature protection
- Power factor correction
- Convection cooling
- Select models are Class I, Division 2 certified for hazardous locations
- LED to indicate DC OK and protection diagnostics
- DC OK Relay for single-phase models 120 Watt and larger
Specifications
SVL1024100 SolaHD Power Supply (240W, 24V, DIN PS 85-264VAC)
Input Voltage, Single Phase | Nominal: 100-240 Vac. Range: 85-264 Vac |
---|---|
Input Voltage, Three Phase | Nominal: 3 x 400-500 Vac (3-phase); Range: 3 x 320-600 Vac (3-phase); or 2 x 360-600 Vac (2-phase) |
Input Frequency | 50/60 Hz |
Operating Temperature | -20°C to +70°C |
Output Power | Single phase: 15-480 Watts; Three phase: 120-960 Watts |
Output Voltage Range | 5, 12, 24, 48 Vdc (Three phase: 24 Vdc only) |
Protection Circuit | Hiccup Mode |
Diagnostic Indicator | Steady Green LED: DC OK |
Mounting | DIN Rail |
Warranty | Two year limited warranty |
