Specifications
Specifications
| POWER SPD TYPE | UL1449 TYPE 1 LISTED |
|---|---|
| VOLTS | 480V |
| AC/DC/DC PV/RF | AC |
| PHASE | 3PH |
| AMPS | N/A |
| AMBIENT MIN | -40º C |
| AMBIENT MAX | +85º C |
| MODES | L-L, L-G |
| VPR | 3000/-/1800/- V |
| MCOV | 1100/-/550/- V |
| IN (15 impulses 8/20µs) | 20 kA |
| SCCR | 200 kA |
| IMAX (8/20µs) | 132 kA |
| TECHNOLOGY | Multi-TMOV |
| NETWORK CONFIGURATION | 3PH, 3W+G, Delta |
| CONNECTION METHOD | 36" #10 AWG LEADS |
| MOUNTING | FLANGE MOUNT |
| MATERIAL | STEEL |
| NEMA RATING (IP RATING) | NEMA 3R, 4, 12 (IP65) |
| FAIL-SAFE BEHAVIOR | Yes, no upstream over current protection required |
| REAL-TIME DIAGNOSTICS | % of protection present LED, audible alarm and remote contacts. Optional surge counter. |
| WEIGHT | 6 lbs |
Documents for
NEMA Rating for
+
| Environments | Type 1 | Type 12 | Type 3R | Type 4 | Type 4X |
|---|---|---|---|---|---|
| Indoor use only | |||||
| Indoor and outdoor use | |||||
| Falling liquids and light splashes | |||||
| Nonhazardous dust, lint, and fibers | |||||
| Washdowns and splashing water | |||||
| Oil and coolant seepage | |||||
| Corrosive agents | |||||
|
Hazardous locations (Class I, Division 1 and 2) |
Related Products
Warranty Information
Manufacturer Warranty: 10-Year warranty
