| Primary brand | NOARK |
|---|---|
| Main function |
Motor Protection Circuit Breaker (MPCB)
|
| Product series / family name |
Industrial controls > Manual Motor Starters (MMSs)
|
| Sub-range name |
Ex9S80 series
|
|
Network frequency
|
50/60 Hz
|
| Functions |
Thermal-magnetic Manual Motor Starter (MMS) / Branch protector
|
| Design |
high magnetic-trip threshold (above 15 x Ie)
|
| Poles |
3-poles (3P)
|
|
Rated current
|
14A...20A current setting range
20A (conventional thermal current; Ith) Matched backup fuse ratings 50A (Class aM fuse at 690Vac) 63A (Class gl/gG fuse at 690Vac) |
|
Frame current rating
|
80 AF
|
|
Rated active power (kW)
|
4kW (AC-3; 230/240Vac)
7.5kW (AC-3; 400/415Vac) 11kW (AC-3; 500Vac) 15kW (AC-3; 690Vac) |
|
Rated power (HP)
|
1HP (110-120Vac; single-phase; UL)
3HP (220-240Vac; single-phase; UL) 5HP (200Vac; 3-phase; UL) 5HP (208Vac; 3-phase; UL) 5HP (220-240Vac; 3-phase; UL) 10HP (460-480Vac; 3-phase; UL) 15HP (575-600Vac; 3-phase; UL) |
|
Rated operating voltage (Ue)
|
(AC) 230/240 V (AC) 400/415 V (AC) 460/480 V (AC) 575/600 V |
|
Rated impulse voltage (Uimp)
|
6 kV
|
|
Rated insulation voltage (Ui)
|
(IEC) 690 V
(UL/CSA) 600 V |
|
Connection type
|
M8 HEX head screw connections
|
|
Short circuit breaking rating
|
42kA (type E; 240Vac; 480Y/277Vac)
30kA (type E; 600Y/347Vac) |
|
Ultimate short circuit current breaking capacity (Icu)
|
100kA (400Vac)
8kA (690Vac) |
|
Service short circuit current breaking capacity (Ics)
|
100kA (400Vac)
8kA (690Vac) |
|
Trip unit type
|
Technology = Thermal-Magnetic (adjustable)
|
|
Protection functions
|
Adjustable thermal protection (Overload) Class 10
Fixed threshold magnetic protection (Short-circuit) Phase failure protection |
|
Protection settings
|
Protection against thermal overload -- 14A...20A (adjustable)
Magnetic instantaneous protection against short-circuit -- 400A |
|
Operating mode
|
Rotary handle operation
|
|
Degree of protection
|
IP20 |
| Dimensions |
H5.51" x W2.17" x D5.39"
H140mm x W55mm x D136.8mm |
|
Ambient air temperature for operation
|
-4...+140°F / -20...+60 °C
|
|
Ambient air temperature for storage
|
-4...+176°F / -40...+80 °C |
|
Technical compatibility with
|
Ex9S80 mtr. starter
|
|
Minimum current
|
14 A
|
|
Maximum current
|
20 A
|
|
Order code / Manufacturer SKU
|
Ex9S80A20B 1600178 |
|
Manufacturer product status
|
Commercialized |
|
Equivalent to
|
1600178 |
|
Compliant with standard(s)
|
Vibration resistance - 5-150Hz with 5gn
Shock resistance - 30gn for 11ms UL 60947-4-1 UL 60947-1 IEC/EN 60947-1 IEC/EN 60947-2 IEC/EN 60947-4-1 IEC/EN 60947-5-1 RoHS CCC NOM CSA 22.2 No. 60947-1 CSA 22.2 No. 60947-4-1 GB/T 14048.1 GB/T 14048.2 GB/T 14048.4 |
| Class | 10 |
|
Operating rate
|
max. 30 Cycles/hour
|
|
Tightening torque
|
6 N.m
|
|
Degree of pollution
|
III |
|
Application type
|
2000m / 6562ft max. operating altitude
|
Benefits
Benefits
