The time-delay, dual-element IDSR series fuses combine a 600V DC capability with indication to provide an ideal solution for many DC applications. These fuses offer a patented, state-of-the-art, solid-state design with maximum reliability and superior performance characteristics.
Features & Benefits
| FEATURES | BENEFITS |
| Excellent short-circuit protection | Improve safety through faster response to fault currents |
| Dual-element design | Provides advanced short-circuit and overload protection |
| Current limiting | Restricts fault current to provide a high degree of circuit protection |
| Visual blown fuse indication | Indication window turns black allowing fast and easy identification of a blown fuse |
Applications
- DC circuits
- Solar inverters
- Motors
- Transformers and solenoids
- Fluorescent lighting
Specifications
| Current Rating (Continuous) in Amps | 6.25 |
|---|---|
| Interrupting Rating | 20 kA @ 600V DC |
| Opening | Slo-Blo/Time Lag (T)/Time Delay |
| Maximum AC Voltage (V) | 600 |
| Voltage Rating (V) | 600 |
| Size | Industrial Cartridge |
| Amp Fraction | 6 1/4 |
| Family Style | Powr-Pro Fuse |
| Fuse Class | Class RK5 |
| Indicating | Yes |
| Interrupt Amperage | 200000 |
| Interrupt Amperage (A) - 2 | 300000 |
| Interrupt Amperage 3 | 20000 |
| Interrupt Voltage Type ACDC - 1 | AC |
| Interrupt Voltage Type ACDC - 2 | AC |
| Interrupt Voltage Type ACDC - 3 | DC |
| Interrupt Voltage | 600 |
| Interrupt Voltage (V) - 2 | 600 |
| Interrupt Voltage - 3 | 600 |
| Mounting Method | Fuse Block / Clip / Holder |
| PG Holder | LFR60030 Series |
