The JTD Series time-delay, dual-element fuses carry the Littelfuse POWR-PRO advanced technology designation and are specifically designed for circuits where space is at a premium. They are ideal for use in systems with high in-rush currents. The JTD fuses offer a patented design that reduces nuisance fuse openings. In addition, they provide Type 2 “No Damage” protection for both NEMA- and IEC-type motor circuit components. These fuses help lower the costs associated with downtime, provide longer fuse life by minimizing nuisance openings, increase system performance by minimizing equipment damage, and improve safety by minimizing accidents.
The POWR-PRO performance brand offers advanced technology protection features, such as self-certification to 300,000 A rms symmetrical and superior current-limiting capability. The self-certification at 300,000 A meets the current trend toward higher short-circuit current ratings (SCCR). Self-certification testing was conducted at a nationally recognized testing laboratory, and the tests were UL witnessed.
Features & Benefits
| FEATURES | BENEFITS |
| POWR-PRO technology | Superior protection against electrical system damage |
| Dual-element | Provides extra time-delay protection with dual-element construction |
| Patented design | Reduces nuisance fuse openings |
| Current-limiting | POWR-PRO current limitation is 8⁄10-600 A. Reduces damage caused by heating and magnetic effects of short-circuit currents |
Applications
- Motor control centers
- Fused combination motor controllers
- Transformers
- UL listed series-rated molded case circuit breaker panels
- General purpose circuits
Specifications
| Current Rating (Continuous) in Amps | 3.5 |
|---|---|
| Interrupting Rating | 20 kA @ 300V DC |
| Opening | Slo-Blo/Time Lag (T)/Time Delay |
| Maximum AC Voltage (V) | 600 |
| Voltage Rating (V) | 300 |
| Size | Industrial Cartridge |
| Amp Fraction | 3 1/2 |
| Family Style | Powr-Pro Fuse |
| Fuse Class | Class J |
| Indicating | No |
| Interrupt Amperage 1 | 200000 |
| Interrupt Amperage (A) - 2 | 300000 |
| Interrupt Amperage 3 | 20000 |
| Interrupt Voltage Type ACDC - 1 | AC |
| Interrupt Voltage Type ACDC - 2 | AC |
| Interrupt Voltage Type ACDC - 3 | DC |
| Interrupt Voltage (V) -1 | 600 |
| Interrupt Voltage (V) -2 | 600 |
| Interrupt Voltage (V) -3 | 300 |
| Mounting Method | Fuse Block / Clip / Holder |
| PG Holder | LFPSJ30 Series |
