Hammond Maufacturinig Enclosures are designed to enclose electrical and/or electronic equipment and protect against harsh, industrial environments for wallmount applications.
Finish
Cover and enclosure are natural stainless steel with smooth brushed finish.
Construction
Formed 304 or 316 stainless steel. Continuously welded seams ground smooth. Door stiffeners are provided where required for increased strength and rigidity. Formed lip on enclosure to exclude flowing liquids and contaminants. 316 Stainless pad lockable handle with 3 point roller latching system secures door. Stainless steel continuous hinge on door may be removed by pulling the stainless steel hinge pin Seamless poured-in place gasket. Collar studs provided for mounting inner panel. Bonding stud provided on door and grounding stud installed in enclosure.
Standards
UL 508 Type 3R, 4, 4X and 12 CSA Type 3R, 4, 4X and 12 Complies with NEMA 3R, 4, 4X, 12 and 13 IEC 60529, IP 66
Applications
Provides high level of protection where equipment is hosed down or otherwise be exposed to wet conditions where corrosion is a serious problem. Ideal for processing plants, utility, outdoor municipal or petro chemical locations where easy yet secure access is required.
Warranty Information
All products manufactured by Hammond are warrant to be free from defects in materials and workmanship for a period of one (1) year from date of shipment from its plant. If within such period any such goods shall be proven to Hammond’s satisfaction to be defective, such goods shall be repaired or replaced at Hammond’s option. Such corrections or replacement of defective goods shall constitute a fulfillment of all liabilities in respect to such goods.
Under no circumstances will credit be allowed for unauthorized rework on any materials. Please contact your local Hammond Representative for warranty information pertaining to any Hammond offered product not manufactured by Hammond.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS AND IMPLIED WARRANTIES WHATSOEVER, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Hammond shall not be liable for damages to goods, property, or persons due to improper installation or through attempts to utilize the goods under conditions which exceed the designed capabilities.
