- High reliability of the contacts (17 V - 5 mA)
- Meet the requirements of IEC 60947-5-1 regarding to mechanically linked contacts;
- Compact product, with a volume up to 62% smaller than a conventional contactor
- Same dimensions for AC and DC versions, simplifying panel designs
- Low consumption DC versions, allowing the use of lower power supplies
- Complete line of accessories, allowing quick and compact assemblies for a wide range of applications
- DIN rail or screw mounting
Specifications
Specifications
| Rated insulation voltage Ui (pollution degree 3) - IEC 60974-4-1 | 690 V |
|---|---|
| Rated insulation voltage Ui (pollution degree 3) - UL, CSA | 600 V |
| Rated operational frequency - minimum | 25 Hz |
| Rated operational frequency - maximum | 400 Hz |
| Mechanical lifespan (AC) | 10 million |
| Mechanical lifespan (DC) | 12 million |
| Electrical lifespan AC3 | Not available |
| Degree protection main terminal | IP20 |
| Degree of protection IP (IEC 60529) - Control circuit | IP20 |
| Rated current | 10 A |
| Rated current AC4 | Not available |
| Rated current AC1 | 10 A |
| Rated operational voltage Ue - IEC 60947-4-1 | 690 V |
| Rated operational voltage Ue - UL/CSA | 600 V |
| Height | 58 mm (2.28 in) |
| Width | 45 mm (1.77 in) |
| Depth | 52 mm (2.05 in) |
| Weight | 194 g |
