Specifications - ABB S801U-Z10
Technical |
|
| Standards | IEC/EN 60947-2 UL 489 CSA C22.2 No.5 |
|---|---|
| Product Name | High Performance MCB |
| Tripping Characteristic | Z |
| Rated Voltage (Ur) | acc. to IEC 60947-2 240 V AC |
| Rated Operational Voltage | acc. to IEC 60947-2 240 V AC |
| Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 690 V |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Input Voltage Type | AC |
| Rated Current (In) | 10 A |
| Rated Operational Current (Ie) | 10 A |
| Rated Short-Circuit Capacity | (400 V) 25 kA (230 V) 25 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (240 V AC) 30 kA (230 V) 30 kA (400 V) 30 kA |
| Rated Conditional Short-Circuit Current (Inc) | (230 V) 30 kA (400 V) 30 kA |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (240 V AC) 25 kA |
| Frequency (f) | 50 / 60 Hz |
| Rated Frequency (f) | 50 / 60 Hz |
| Power Loss | 1.5 W at Rated Operating Conditions per Pole 1.5 W |
| Contact Position Indication | ON / OFF / TRIP |
| Energy Limiting Class | 3 |
| Number of Poles | 1 |
| Number of Protected Poles | 1 |
| Overvoltage Category | III |
| Release Type | Z |
| Actuator Marking | I / O |
| Accessories Available | Yes |
| Connecting Capacity | Flexible 0...50 mm² Rigid 0...70 mm² |
Environmental |
|
| Ambient Temperature | -25...60 °C |
| Ambient Air Temperature | Operation -25...60 °C |
| Degree of Protection | IP20 |
| Pollution Degree | 2 |
| RoHS Status | Following EU Directive 2011/65/EU |
Dimensions |
|
| Width in Number of Modular Spacings | 1.5 |
| Product Net Width | 27 mm |
| Product Net Height | 95 mm |
| Product Net Depth / Length | 82.5 mm |
| Product Net Weight | 245 g |
| Built-In Depth (t2) | 82.5 mm |
Classifications |
|
| ETIM 6 | EC000042 - Miniature circuit breaker (MCB) |
| ETIM 7 | EC000042 - Miniature circuit breaker (MCB) |
| ETIM 8 | EC000042 - Miniature circuit breaker (MCB) |
| EPLAN Catalog Tree | Electrical engineering / Protection devices / General |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Business |
| CN8 | 85362020 |
| UNSPSC | 39121603 |
| eClass | V11.0 : 27141901 |
| IDEA Granular Category Code (IGCC) | 4899 >> Miniature circuit breaker (MCB) screw-in model |
| Object Classification Code | F |
