BCAL-2 DWB | BCAL Auxiliary and Alarm Switch

Weg DWB160- Series Internal AccessoryFeatures built-in terminal blocks; these terminal blocks will accept 20 to 16 AWG (0.5 to 1.5MM2) Tightening torque of 6.9 lb.in. (0.8 N. m.).BC Auxiliary Switch    Indicates remote circuit breaker status "open" (OFF) or "closed" (ON) through SPDT form C contacts.AL Alarm Switch    Indicates circuit breaker has tripped due to overload, short-circuit, shunt tripor undervoltage-trip release conditions through SPDT form C contact.    Contact opens when circuit breaker is reset    Offers provision for audio and visual indication of tripped breakerElectrical Characteristics    Rated Voltage: 125/250VAC    Type of Load: Resistive    Switching Capacity: 6 Amp
