Polycarbonate Enclosure with Hinged Cover and Stainless-Steel Snap Latch
Factory New
Tom Test
Representative image shown
$75.00
Was $100.00
MSRP: $100.00
Save: $25.00

Complete My Build Top

This item:

+
+
Total price:
Free Shipping
Free Technical Support
Decrease Quantity: Increase Quantity:
In Stock
Availability: Ships within 1 business day.
Product Details

Allied Moulded, NEMA 4X rated, Polyline Series, 12"x10"x6", Wall mount enclosure assembly

SKU:
ABC
Weight:
2.00 LBS
Dimensions:
12in x 10in x 6in
Material:
Polycarbonate
Enclosure Type:
Wall Mounted
Cover Type:
Opaque
Closure Type:
Metal Snap Latch
Mounting Type:
Nonmetal Flange
Associated Product
Associated Set 2

Complete My Build Bottom
verified Verified fit These products are compatible with the

Inner Panels
Fans
Filters
Heaters
Ventilation
Mounting

Build My Enclosure

Total price: $0

  • Description
  • Features
  • Application
  • Standards
  • Specifications
  • Documents

This is a test description Update request.

Features for AMP1206LF

Features for AMP1206LF

Non-corrosive, non-conductive, light weight with lower installation cost, easy to modify and longer life cycle compared to steel. Rigid design with back panel inserts plus nonmetallic mounting brackets and a gasket system encased in a continuous channel on the cover.

Application for AMP1206LF

Application for AMP1206LF

Enclose and protect electrical and electronic controls, instruments or components for indoor and outdoor applications. Especially well suited for extreme temperature and corrosive environments.

Standards for AMP1206LF

Standards for AMP1206LF
  • UL 508A, UL 50 and UL 50E Types 1, 2, 3, 3R, 4, 4X, 12 and 13
  • CSA C22.2 No. 94 Types 1, 2, 3, 3R, 4, 4X, 12 and 13
  • Complies with:
    1. EN / IEC 60204-1 and 60529 Type IP66
    2. RoHS directive

Specifications for AMP1206LF

Specifications for AMP1206LF
Enclosure Type JIC Size
Cover Type Opaque
Closure Type Metal Snap Latch
Mounting Description Nonmetal flange fastened to back side brass inserts
Height 11.93 in (303.022 mm)
Width 10.15 in (257.81 mm)
Depth 5.94 in (150.876 mm)
Usable Depth 6.06 in (153.924 mm)
Volume 829 cu. in. (13584905.9 cu mm)
Color Gray (RAL 7035)
Material Polycarbonate box and cover
Additional Materials 316 stainless steel external hardware (hinges/latches/fasteners), Polycarbonate mounting brackets, Plated carbon steel internal hardware, Brass inserts, Polyurethane (FIP) Formed-In-Place gasket system

Documents

NEMA Rating for

Nema active
N1
Indoor
Protection from fingers, tools and small objects
Nema active
N12
Indoor
Protection from dust and light splashes of water
Nema active
N3R
Outdoor
Protection from rain, snow and sleet
Nema not active
N4
Outdoor
Protection from rain, snow, sleet, and hose directed water
Nema not active
N4X
Outdoor
Protected from rain, snow, sleet, and pressure rated hose directed water from all angles
